Transistor output |
4 channels/unit |
Pt100, JPt100 |
Full scale × (±0.3%) |
Full scale × (±0.7%) |
500ms/4 channels |
1 ~ 100s |
1 MΩ |
0 to 100s (0: Input filter OFF) |
-50.00 to 50.00% |
Upscale processing |
PID ON/OFF pulse or 2-position control |
Can be set by auto tuning |
0.0-1000.0% (0.0:2 position control) |
0 to 3600s (0: P control, PD control) |
0 to 3600s (0: P control, PI control) |
Within the temperature range set by the platinum resistance thermometer used |
0.1 ~ 10.0% |
ON/OFF pulse |
10 to 30 VDC |
0.1A/1 point, 0.4A/1 common |
0.4A, 10ms |
0.1 mA or less |
DC1.0V (TYP.) 0.1A, DC2.5V (MAX.) 0.1A |
2 ms or less |
2 ms or less |
Between input terminal and programmable controller power supply, between input channels: Transformer isolation |
Between input terminal and programmable controller power supply, between input channels: 500 VAC for 1 minute |
Between input terminal and programmable controller power supply, between input channels: DC500V 20MΩ or more |
URD Co., Ltd. current sensor , CTL-12-S36-8 (0.0-100.0A) , CTL-12-S36-10 (0.0-100.0A) , CTL-12-S56-10 (0.0 ~100.0A) / CTL-6-P (0.00 ~ 20.00A) / CTL-6-PH (0.00 ~ 20.00A)
|
Full scale × (±1.0%) |
3 ~ 255 |
18-point screw terminal block (M3 screw) x 2 |
32 points, 2 slots (I/O allocation: 16 empty points + 16 intelligent points) |
0.33A |
98 mm |
55.2 mm |
112 mm |
0.30kg |
