Software specifications | ||
OS | ||
Programming language | ||
Hardware specifications | ||
CPU | system | |
Endian format | ||
Memory capacity | Work RAM | |
Standard RAM | ||
Standard ROM | ||
Battery backup RAM | ||
Compact flash card section | interface | |
Power supply | ||
Built-in Ethernet port (CH1, CH2) part | interface | |
Communication method | ||
Data transmission rate | ||
Transmission method | ||
Maximum segment length | ||
External wiring compatible connector | ||
Support function | ||
RS-232 connector (CH3) section | interface | |
Communication method | ||
Synchronization method | ||
Transmission speed | ||
Transmission distance | ||
data form | Start bit | |
Data bit | ||
Parity bit | ||
Stop bit | ||
Parity check | ||
Thumb check code | ||
Transmission control | ||
External wiring compatible connector | ||
USB connector | interface | |
connector | ||
transfer speed | ||
Power supply | ||
Number of input/output points | ||
Clock function | Display information | |
accuracy | ||
Allowable instantaneous power failure time | ||
DC5V internal current consumption | ||
External dimensions | Height (H) | |
Width (W) | ||
Depth (D) | ||
mass |
VxWorks Version 6.4 |
C language (C/C++) |
SH4A |
Little endian |
128 MB |
In basic function mode: 3M bytes In function expansion mode: 0 to 3M bytes |
In basic function mode :-In function expansion mode: 12 MB |
In basic function mode: 512K bytes In function expansion mode: 512K bytes to 3584K bytes |
TYPE I (up to 8 GB) TYPE II card cannot be used I/O card such as modem card cannot be used |
DC+3.3V, maximum 150mA |
10BASE-T/100BASE-TX |
Full duplex/half duplex |
10Mbps(10BASE-T)/100Mbps(100BASE-TX) |
Baseband |
100m |
RJ45 |
Auto negotiation function (communication speed/communication method automatic recognition) Auto MDI/MDIX (straight/cross automatic recognition) |
RS-232 compliant |
Full duplex/half duplex |
Asynchronous method |
9600, 14400, 19200, 28800, 38400, 57600, 115200bps |
Up to 15m |
1 |
7/8 |
1/None |
1/2 |
Yes (even/odd)/No |
Arinashi |
Flow control (RS/CS control) |
Round miniature connector (10P plug) |
Supports USB 2.0 standard |
Connector type mini-B |
12Mbps (Full Speed) |
Self power |
4096 points (X/Y0-FFF) |
Year, month, day, hour, minute, second, day of the week (leap year automatic detection) |
Day difference: -10.89 to +8.46s (0 to 55℃) Day difference: -4.32 to +5.25s (25℃) |
Depends on power supply unit |
0.97A |
98 mm |
27.4 mm |
115 mm |
0.24kg |
Ambient temperature | ||
Ambient storage temperature | ||
Ambient humidity | ||
Storage ambient humidity | ||
Vibration resistance | Conforms to JIS B 3502, IEC 61131-2 | If there is intermittent vibration |
When there is continuous vibration | ||
Shock resistance | ||
Atmosphere | ||
Altitude used | ||
Installation location | ||
Overvoltage category | ||
Pollution degree | ||
Device class |
0 ~ 55 ℃ |
-25 ~ 75°C |
5 to 95% RH, no condensation |
5 to 95% RH, no condensation |
Frequency: 5 to 8.4Hz, Single amplitude: 3.5mm Frequency: 8.4 to 150Hz, Constant acceleration: 9.8m/s 2 Sweep frequency: 10 times in each direction of X, Y and Z |
Frequency: 5 to 8.4Hz, Single amplitude: 1.75mm Frequency: 8.4 to 150Hz , Constant acceleration: 4.9m/s 2 |
Conforms to JIS B 3502, IEC 61131-2 (147 m/s 2 , XYZ 3 directions each 3 times) |
No corrosive gas |
0 ~ 2000m |
In the control panel |
Ⅱ or less |
2 or less |
Class I |
