Item | Model | ||
---|---|---|---|
CJ1W-NC113/133 | CJ1W-NC213/233 | CJ1W-NC413/433 | |
Power supply voltage | 5 V DC (for the PCU itself) | ||
24 V DC (external power supply) | |||
5 V DC (external power supply; line driver output only) | |||
Allowable power supply voltage range | 4.75 to 5.25 V DC (for the PCU itself) | ||
21.6 to 26.4 V DC (external power supply) | 22.8 to 25.2 V DC (external power supply) | ||
4.75 to 5.25 V DC (external power supply; line driver output only) | |||
Internal current consumption | 250 mA max. at 5 V DC | 250 mA max. at 5 V DC | 360 mA max. at 5 V DC |
Current consumption of external power supply | NC113: 30 mA max. at 24 V DC NC133: 10 mA max. at 24 V DC NC133: 60 mA max. at 5 V DC | NC213: 50 mA max. at 24 V DC NC233: 20 mA max. at 24 V DC NC233: 120 mA max. at 5 V DC | NC413: 100 mA max. at 24 V DC NC433: 30 mA max. at 24 V DC NC433: 230 mA max. at 5 V DC |
External dimensions | 90 (H) × 31 (W) × 65 (D) (all models) | ||
Weight | 100 g max. | 100 g max. | 150 g max. |
Ambient operating temperature | 0 to 55 ° C | 0 to 50 ° C * |
