[중고] NMX-754-1212 CONDOR (SL POWER) 파워서플라이 > POWER SUPPLY

INPUT

- AC Input : 90-264 Vac continuous range, 47 to 63 Hz. Internally fused for 15 A

- Power Factor : 0.99 typical at full load. Meets EN61000-3-2 Class A.

- Inrush : Cold start ac current  is less than 65 A at 115 Vac and 130 A at 230 Vac. Limited by thermistor.

- Brownout Protection : Holds  regulation  to  85  Vac.

- Holdup Time : 20 ms minimum after removal of power at full load.

- Efficiency : 75%  typical.

OUTPUT

- Adjustability : Outputs #1 and 2 user adjustable ±5% minimum Output #3 tracks #2; initial accuracy ±4%. Output #4 user adjustable ±5% minimum, or +5% only if voltage is 5.2 V.

- Line & Load Reg : Outputs #1, 2, and 4 hold ±1% over ac input range and 0 to 100% load change. Output #3 requires 20% minimum load on outputs #2 and 3 to hold ±4%.

- Ripple & Noise : Less than 1% p-p or 100 mV, whichever is greater.

- Remote Sense (Outputs #1 and 2) : Compensates  for  250 mV total line drop. Open sense lead protection. (See Redundancy.)

- Temperature Coefficient (Outputs #1, 2, and 4) : 0.02% per degree C.

- Stability : 0.1% over 8 hours after 30 minutes warm-up.

- Transient Response (Outputs  #1,  2,  and  4) : Output  voltage returns to within 1% in less than 500 μs for a 50% load change.

- Peak transient does not exceed  5%.

- Overload  Protection : All outputs are protected against overload and short  circuit.  Automatic recovery upon removal of fault.
